Technical Specification
| PH Range | (-1.999 pH to 19.999 pH) |
| PH Resolution | 0.1 pH or 0.01 pH or 0.001 pH |
| PH Accuracy | Meter: ±0.002 pH |
| MV Measuring range(mV/ORP/EH) | -1999.9 mV to 0 mV to 1999.9 mV |
| MV Resolution | 0.1 mV |
| MV Accuracy | ±0.03% FS |
| Conductivity Measuring range | :(0.00 to 20.00) μS/cm (20.0 to 200.0)μS/cm (200 to 2000) μS/cm (2.00 to 20.00) mS/cm (20.0 to 200.0) mS/cm (200 to 2000) mS/cm (K=10 |
| TDS | (0 to 100) g/L |
| Salinity | (0 to 100) ppt |
| Data storage | 300 groups |
| Power | DC 9 V/300 mA |
| Communication connector | RS232 |
| Environmental humidity | ≤75% |
| IP rating | IP54 Dustproof and waterproof |
| Temp. compensation range | 50 °F to 231.8 °F (-10 ℃ to 110 ℃) |
| Environment temperature | 41°F to 95 °F (5 ℃ to 35 ℃) (0.01 grade)
59 °F to 86°F (15 ℃ to 30 ℃) (0.001 grade) |
| Temp. compensation range | 32 °F to 212 °F (0 °C to 100 °C) (automatic or manual) |
| Size | 6.3 in x 7.48 in x 2.7 in (160 mm × 190 mm × 70 mm) |
| Weight | 1.94 lb. (880 g) |
