Key Features
- Various probes optional, probe auto matching.
- Durable ruby probe, more wear and precise.
- Full metal shell design, sturdy, portable, high reliability.
- Alarm function when overrun the settable limiting range.
- Five statistics values [MEAN, MAX, MIN, NO., S.DEV] higher measurement accuracy.
- Large storage, easy to delete single or multiple saved values..
- PC software optional, convenient the data transmission, analysis, printing etc.
Technical Specifications
| Measuring range | 0-1250μm, depends on probes, MAX 10mm for the probe F10. |
| Working principle | Magnetic & Eddy |
| Substrate | FE / NFE base |
| Resolution | 0.1μm |
| Display | 128×64 LCD with backlight |
| Accuracy | ±2%H+1um Note: H is thickness reading |
| Memory | 5 files x 100 values |
| Unit switch | Metric (μm) Imperial (mil) |
| Working temperature | 14F~122F(-10~50°C ) |
| Power | AA battery 2pcs |
| Weight | 0.74lbs.(340g) |
| Size | 4.52*2.63*1.22 in (115*67*31mm) |
