Overview
This brass ultrasonic water meter is engineered for accurate and efficient water flow measurement across residential, commercial, and industrial applications. Built with advanced transit-time ultrasonic technology, it delivers high precision over a wide flow range of 0.5 to 100 m³/h. The IP68 protection ensures reliable operation even in harsh environmental conditions, while its durable brass construction provides long service life and resistance to wear. Featuring Modbus connectivity and optional RS485 interface, it integrates seamlessly into modern monitoring and control systems. The digital LCD display with backlight allows for easy reading, and the meter’s ability to log historical data supports effective water management. Designed with minimal maintenance needs due to its non-mechanical structure, it is suitable for both horizontal and vertical installations. With a robust pressure rating and energy-efficient long-life battery, this ultrasonic water meter combines accuracy, durability, and smart functionality for reliable water measurement.
Features
- Transit-time ultrasonic measurement principle
- Brass construction for durability and strength
- Wide flow measurement range: 0.5–100 m³/h
- High accuracy with Class B performance standards
- IP68-rated waterproof protection
- LCD digital display with backlight for easy reading
- Modbus connectivity with optional RS485 interface
- Historical data logging for up to 24 months
- Long-life lithium battery power supply
- Flexible horizontal or vertical installation options
Technical Specifications
| Parameter | Details |
| Type | Ultrasonic Meters |
| Protection Class | IP68 |
| Flow Rate | 0.5 – 100 m³/h |
| Measurement Range | 0.5 – 100 m³/h |
| Connectivity | Modbus |
| Customized Support | OEM, OBM, ODM |
| Material | Brass |
| Nominal Diameter | DN20 |
| Parameter | Details |
| Measuring Principle | Transit-Time Ultrasonic Technology |
| Accuracy Class | Class B (±2% under rated conditions) |
| Temperature Range | -10°C to +55°C |
| Pressure Rating | Up to 1.6 MPa |
| Display Type | Digital LCD with Backlight |
| Data Logging Capability | Up to 24 Months Historical Storage |
| Response Time | ≤ 3 Seconds |
| Communication Interface | RS485 Optional |
| Installation Orientation | Horizontal or Vertical |
| Power Supply | Lithium Battery (Long-Life) |
| Maintenance Requirement | Minimal, No Moving Parts |
| Standard Compliance | ISO 4064 / GBT 778.1-2007 |
