Overview
Enviro Testers Multi-Pixel Gas Sensor is designed for indoor air quality applications. It integrates multiple sensing elements on a single chip to provide accurate detection of Total Volatile Organic Compounds (TVOC) and equivalent CO₂ (eCO₂) levels. This device uses an I²C interface for easy integration into IoT devices, air purifiers, and smart ventilation systems, ensuring precise environmental monitoring.
Features
- Detects TVOC and eCO₂ concentrations
- I²C interface for simple integration
- Compact 2.45 x 2.45 x 0.9 mm³ package
- Low power consumption of 48 mA at 1.8V
- Suitable for air purifiers and smart ventilation systems
Technical Specifications
| Measurement Range (TVOC) | 0 to 60,000 ppb |
| Measurement Range (eCO₂) | 400 to 60,000 ppm |
| Operating Voltage | 1.8V |
| Power Consumption | 48 mA |
| Interface | I²C |
| Package Dimensions | 2.45 x 2.45 x 0.9 mm³ |
| Operating Temperature | -40 °F to 185 °F (-40 °C to 85 °C) |
| Humidity Range | 0% to 100% RH |
