Features
- Measures and records differential and gauge pressure
- Three modes: single, manual (99 points), automatic (12,000 points)
- Supports 11 selectable units (metric and imperial)
- Programmable automatic recording with fast 0.5s response time
- RS232 interface with software for easy PC data transfer
- Upload pre-edited headers from PC to the device
- High accuracy: ±0.3% of full scale with excellent repeatability
- Comes with hoses, carry case, software CD, and cable
Technical Specifications
| Pressure Range & Resolution | ±100.0 psi (0.1 psi) ±689.5 kPa (0.4 kPa) ±5171 mmHg (3 mmHg) ±7.031 kg/cm² (0.004 kg/cm²) ±6895 mbar or hPa (4 mbar or hPa) ±6.895 bar (0.004 bar) ±2768 inH₂O (2 inH₂O) ±7004 cmH₂O (4 cmH₂O) ±203.6 inHg (0.2 inHg) ±230.7 ftH₂O (0.2 ftH₂O) ±1600 oz/in² (1 oz/in²) |
| Accuracy (at 77 °F / 25 °C) | ±0.3% of full scale |
| Repeatability | ±0.2 to 0.5% of full scale |
| Linearity/Hysteresis | ±0.29 to 1% of full scale |
| Combined Accuracy | ±1.0% of full scale |
| Response Time | 0.5 seconds |
| Units of Measurement | 11 selectable (metric and imperial) |
| Recording Capacity | Up to 12,000 automatic points or 99 manual points |
| Interface | RS232 with PC software support |
| Display | LCD, 1.77 in x 1.02 in (45 mm x 26 mm) |
| Power Supply | 4 x AAA batteries or 9 V adapter |
| Operating Temperature | 32 °F to 122 °F (0 °C to 50 °C) |
| Operating Humidity | <80% RH |
| Storage Temperature | -4 °F to 122 °F (-20 °C to 50 °C) |
| Storage Humidity | <90% RH |
| Weight | ~9.17 oz (260 g) |
| Dimensions | 6.73 in x 2.76 in x 1.55 in (171 mm x 70 mm x 39.5 mm) |
