Overview
This device is a digital gauge designed for measuring the thickness of coatings on various surfaces, particularly car paint. It uses a non-destructive method to measure the thickness of non-magnetic coatings (like paint) on magnetic substrates (like steel) and insulating coatings on non-magnetic substrates (like aluminium). The device is portable and user-friendly, making it suitable for a range of applications, including automotive detailing, quality control, and inspecting used vehicles for hidden damage or repainting. This product is a reliable tool for quickly and accurately assessing the thickness of films and coatings.
Features
- Non-destructive measurement of coating thickness.
- Suitable for measuring non-magnetic coatings on magnetic substrates and insulating coatings on non-magnetic substrates.
- Portable and user-friendly design.
- Ideal for automotive detailing, quality control, and vehicle inspection.
Technical Specifications
| Measuring Range | 0 μm to 5000 μm（0 mm to 5mm）( 0 in to 0.197 in ) |
| Using Environment | 0 ℃ to 50 ℃ (32 ° F to 122 ° F) and 20% RH — 90% RH, not strong magnetic place. |
| The Thinnest Matrix | 0.4 mm (0.016 in) |
| Measurement Accuracy | ± ( 3% H + 2 μm ) |
| Resolution Ratio | 0.1 μm or 1 μm |
| Minimum Curvature | Convex 5 mm (0.20 in); concave 25 mm (0.98 in) |
| Minimum Matrix | 18 mm x 15 mm (0.71 in × 0.59 in) |
| Power | Three (7) alkaline battery |
| Size | 126 mm x 64 mm x 28 mm (4.96 in × 2.52 in × 1.10 in) |
| Weight | 106 G (3.74 oz) (excluding battery) |
