Overview
Equipped with a high performance linear CCD sensor. Through high-speed and high precision signal acquisition, analysis and processing technology, the Digipol-R is equipped with a semiconductor Parte super temperature control system. It can measure the refractive index (Nd) and the mass fraction of sugar solution (Brix) of transparent, translucent, dark and viscous liquid with high accuracy and efficiency.
Features
- Built-in Parpaste temperature control, improve accuracy and stability.
- LED cold light source instead of the traditional sodium light lamp and halogen tungsten lamp.
- Compliance with 21CFR Part 1 audit trail, pharmacopoeia and electronic signature.
- Support network printing, support data statistical retrieval.
- Multi-level authority management, authority can be freely configured.
- 7 “touch color screen, user-friendly operation interface.
- The whole machine has passed TART and CE certification.
Technical Specifications
| Parameter | Specification |
| Range | 1.3000 – 1.7000 (nD) |
| Resolution | 0.00001 (nD) |
| Precision | ±0.00002 |
| Brix Range | 0 – 100% (Brix) |
| Brix Accuracy | ±0.1% (Brix) |
| Test Mode | Refractive index / sugar content or customized |
| Temperature Control Method | No |
| Temperature Control Range | Room temperature |
| Temperature Control Stability | Room temperature |
| Light Source | LED |
| Wavelength | 589 nm |
| Prism | Sapphire |
| Sample Cell | Stainless steel |
| Detection Method | High-resolution CCD |
| Display Method | 7 inch TFT color touch screen |
| Data Storage | 32GB |
| Output Method | USB, RS232, RJ45, SD card, U disk |
| User Management | Yes (Four-level authority management) |
| Audit Trail | Yes |
| Electronic Signature | Yes |
| Custom Method Entry | Yes |
| Export File to Verify High-End Production (MDS) | Yes |
| WiFi Printing | Yes |
| Export in Multiple File Formats | PDF & Excel |
| Size | 360 × 300 × 155 mm |
| Power Supply | 220V / 50Hz |
| Weight | 5 kg |
