Overview
ETECMTG-141 is the coating thickness gauges work either on the magnetic induction principle or on the eddy current principle, depending on the type of probe used. For measurement on steel substrates, the gauge works on the magnetic induction principle, for measurement on non-ferrous metal substrates; it works on the eddy current principle. Measured values and user information are shown on LCD. The display with backlight ensures easy reading of screen data in dark conditions.
Features
- Measured Coatings: Non-magnetic coatings (e.g. paint, zinc) on steel; Insulating coatings (e.g. paint, anodizing coatings) on no-ferrous metals
- Operating with MENU easily
- Memory for 1500 readings
- Delete single readings and all group readings easily
- Error indication
- Data transferred to PC via USB for analysis
- Disable Auto-Power-off function via MENU setting
Technical Specifications
| Sensor probe | F | N |
| Working principle | Magnetic induction | Eddy current principle |
| Measuring range | 0 1350 | 0 1350μm |
| 0 53.1mils | 0 53.1mils | |
| Guaranteed tolerance
(of reading) |
0 1000
(2.5%+2 ) |
0 1000
(2.5%+2 ) |
| 1000 1350
( 3.5%) |
1000 1350
( 3.5%) |
|
| 0 mils
( mils) |
0 mils
( mils) |
|
| 39.3 mils( | 39.3 mils( | |
| Precision | 0 100 (0.1 ) | 0 100 (0.1 ) |
| 100 1000 (1 ) | 100 1000 (1 ) | |
| 1000
(0.01mm) |
1000
(0.01mm) |
|
| 0 mils(0.01mils) | 0 mils(0.01mils) | |
| 10 mils(0.1mils) | 10 mils(0.1 mils) | |
| Minimum curvature radius | 1.5mm | 3mm |
| Diameter of Minimum Area | 7mm | 5mm |
| Minimum Measureable Thickness | 0.5mm | 0.3mm |
| Overload Display | —- | —- |
| Working temperature | 00C 400C(320F 1040F) | |
| Working relative humidity | 20% | |
