Overview
This dual head digital peristaltic pump delivers precise liquid transfer with adjustable flow rates up to 2200 ml/min. Designed with ABS and stainless steel, it offers strength, chemical resistance, and compact dimensions. The LED digital interface allows easy control of speed, timing, and direction. Versatile external connectivity makes it ideal for laboratories, medical use, and industrial fluid handling.
Features
- Adjustable flow range from 0–2200 ml/min
- Dual head design supports YZ15/25 pump tubes
- LED digital display with 0.1 rpm resolution
- Forward, reverse, and full-speed operation modes
- RS485 communication for remote integration
- External control via 0–5V, 0–10V, 4–20mA, 0–10kHz
- Programmable timing from 0.1 seconds to 99 hours
- Durable ABS and stainless steel housing
- Compact size and optional foot switch
Technical specifications
| Pump Type | Digital dual head peristaltic pump |
| Flow Range | 0 – 2200 ml/min |
| Motor Power | 30W |
| Speed Range | 0–100 rpm, 0–300 rpm, 0–600 rpm |
| Speed Resolution | 0.1 rpm (≤100 rpm), 1 rpm (>100 rpm) |
| Operation Modes | Forward, reverse, full speed |
| Adjustment Method | Membrane key adjustment |
| Display Type | 3-digit LED display |
| Timing Range | 0.1 seconds – 99 hours |
| Direction Control | Forward and reverse |
| Start/Stop Control | Foot switch optional |
| External Control Inputs | 0–5V, 0–10V, 4–20mA, 0–10kHz |
| Communication | RS485 serial control |
| Control Functions | Start, stop, direction, speed |
| Power Options | ≤20W, ≤50W, ≤75W |
| Voltage Range | AC 85–264V, 47–63Hz |
| Capacity | 0–2200 ml/min |
| Material | ABS and stainless steel |
| Build Quality | Durable and chemical resistant |
| Applications | Laboratory, medical, industrial, dosing |
| Installation | Compact, easy to set up |
| Noise Level | Low operation noise |
| Dimensions (with head) | 235 × 142 × 148 mm |
| Dimensions (without head) | 237 × 148 × 148 mm |
| Star Mode | LED display speed/timing |
| Tube Compatibility | YZ15, YZ25 pump tubes |
| Safety | Stable operation with overload protection |
| Timing Function | Programmable delay and cycle timing |
| Working Environment | 0–40℃ / 32–104℉, humidity <80% |
| Weight | 3.6 – 4 kg |
