Technical Specifications
| Power Supply | AC 100 V to 240 V 50 Hz |
| Motor Power | 120 W |
| Speed Range | HTD 13145: 3, 6, 100, 200, 300, 600 r / min |
| Measuring Accuracy | 1 m Pa.s 25 m Pa·s: ±1 m Pa·s (Newtonian Fluid) |
| Above 25 m Pa·s: ±4 % (Newtonian Fluid) | |
| Viscosity Measuring Range | Newtonian Fluid:
0 m Pa·s to 30000 m Pa.s (F1 Measure component) 0 m Pa·s to 6000 m Pa.s (F0.2 Measure component) |
| Non-Newtonian Fluid:
0 m Pa·s to 150 mPa.s (F1 Measure component) 0 m Pa·s to 30 m Pa.s (F0.2 Measure component) |
|
| Shear Stress | Shear Stress:
0 Pa to 153.3 Pa (F1 Measure component) 0 Pa to 30.7 Pa (F0.2 Measure component) |
| Net Weight / Gross Weight | 13.71 lb (6.22 kg) /17.81 lb (8.08 kg) |
| Overall Dimensions | 11.81 in x 11.42 in x 17.32 in (300 mm x 290 mm x 440 mm) |
