Features
- Color High contrast LCD touchscreen, 7.0 inches
- Multi-reading feature allows auto-read, timed-read and continuous-read
- Automatic/Manual temperature compensation ensures accurate results
- Data Storage 1000 sets for each parameter
- Data analysis feature helps user review, compare and recalculate results
- Support for USB or RS-232 communication
- Reset feature automatically resumes all settings back to factory default options
- IP 54 waterproof
- 1-6 points calibration
- 1-6 points calibration with Standard Recognition
- Selectable pH buffer groups, including NIST, DIN, GB
- Support for pH standard group customization
- Automatic electrode diagnosis with pH slope and offset display
Technical Specifications
| pH Range | -2.000 ph to 20.000 pH |
| pH Resolution | 0.1, 0.01, 0.001 pH |
| pH Accuracy | ± 0.002 pH |
| pH Calibration Points | Up to 6 |
| pH Standard Recognition | NIST, GB, DIN buffers |
| mV or ORP Range | -2000.00 to 2000.00 mV |
| mV or ORP Resolution | 0.1 mv, 0.01 mV |
| mV or ORP Accuracy | ± 0. 1 mV or ± 0.03 % |
| mV or ORP ORP Calibration Points | 1 custom point 2 custom point (Relative mV) |
| pX Range | -2.000 px to 20.000 pX |
| pX Resolution | 0. 1, 0.01, 0.001 pX |
| pX Accuracy | ± 0.002 pX |
| pX Calibration Points | Up to 6 |
| ISE Range | 0 to 19990 |
| ISE Units | mol/L, mmol/L, g/L, mg/L, μ g/L |
| ISE Resolution | Up to 4 significant digits |
| ISE Accuracy | ± 0.3 % |
| ISE Calibration Points | Up to 6 |
| Reading Mode | Auto Read (Fast, Medium, Slow), Timed, Continuous |
| Reading Prompts | Reading, Stable, Locked |
| Temp. Compensation | ATC, MTC |
| Data Storage | 1000 Groups |
| pH Electrode | BNC (Q9) |
| Temp. Probe | 6-pin Mini-DIN |
| USB, RS 232 | USB 2.0 flash memory device, printer, PC |
| Auto Shutdown | 1 min or 60 min, off |
| IP Rating | IP 54 |
| Power | AC Adapter, 100-240V AC input, DC 24 V output |
| Temperature Unit | ºC |
| Temperature Resolution | 0.1 |
| Temperature Accuracy | ± 0. 1 |
| Temperature Range | 41 °F to 266 °F (-5 ºC to 130 ºC) |
| Dimensions | 11.02 in x 11.02 in x 5.11 in (280 mm × 280 mm × 130 mm) |
| Weight | 5.51 lb (2.5 kg) |
