Features
- Color High contrast
- LCD touchscreen
- Intelligent operation system
- Multi-reading feature
- Automatic/Manual temperature
- Ensures accurate results
- Data Storage1000 sets
- Data analysis feature
- Support for USB
- RS-232 communication
- Automatically resumes all settings
- IP54 waterproof
- 1-6 points calibration
- Standard Recognition
- Selectable pH buffer groups
- Support for pH standard group customization
- Automatic electrode diagnosis
Technical Specifications
| Parameters | pH/Temp.(mV/ORP) |
| pH Range | -2 pH to 20 pH |
| pH Resolution | 0.1 pH, 0.01 pH, 0.001 pH |
| pH Accuracy | ±0.002 pH |
| pH Calibration Points | Up to 6 |
| pH Standard Customization | Yes |
| pH Calibration Reminder | Yes |
| pH Standard Recognition | NIST, GB, DIN, USA, MERK, JIS buffers |
| pH Slope Limit | Yes |
| mV/ORP Range | -2000 mV to 2000 mV |
| mV/ORP Resolution | 0.1 mV, 0.01 mV |
| mV/ORP Accuracy | ±0.1 mV or ±0.03 % |
| mV/ORP EH ORP Mode | Yes |
| mV/ORP ORP Calibration Points | 1 custom point (relative mV) |
| Measurement Reading Mode | Auto Read (Fast, Medium, Slow), Timed, Continuous |
| Measurement Reading Prompts | Reading, Stable, Locked |
| Measurement Temp. Compensation | ATC, MTC |
| Data Management Data Storage | 1000 Groups |
| Data Management GLP Features | Yes |
| Data Management Log Management | Yes |
| pH Electrode | BNC (Q9) |
| Temp. Probe | 4-pin aviation connector |
| USB | USB 2.0 flash memory device, PC, scanner |
| RS 232 | printer, auto-sampler |
| Backlight | Yes |
| Auto Shutdown | 1 min to 60 min, off |
| IP Rating | IP54 |
| Date And Time | Yes |
| Power | AC Adapter, 100 V to 240 V AC input, DC 24 V output |
| Range | 14 ºF to 275 ºF (-10 to 135 ºC) |
| Unit | ºC, ºF |
| Resolution | 0.1 |
| Accuracy | ±32.18 ºF (±0.1 ºC) |
| Dimension | 8.66 in x 7.67 in x 2.67 in (220 mm ×195 mm ×68 mm) |
| Weight | 2.09 lb. (950 g) |
