Overview
Enviro Testers area monitor radiation meter is mainly used in continuous monitoring. It can connect 32 probes at the same time, display the all-dose rate data of each probe and send the alarm signal with light and sound basic through the predestined alarm dose rate. The instrument has the advantages of the wide range, long transmit distance, multiple external probes and remote management.
Features
- External alarm lamp integrally with the probe design, large screen display
- A monitor can connect 32 probes at the same time.
- Digital probe, the measurement results are transmitted to the monitor
- Special moisture and dust-proof design
- The probe and monitor will sound an alarm
- The monitor has RS-485 communication interface
- Used to send the measurement results to the remote computer monitoring system protocol
- Reasonable design, beautiful structure, easy to operate
Technical Specifications
| Radiation Occasions | X ray, gamma ray |
| Monitor | Double GM counter tube |
| Display Unit | μSv/h, mSv/h |
| Measuring Range | 0.1 μSv/h to 1 Sv/h |
| Energy Response | 48 keV to 3 MeV, ≤ ± 30 % |
| Response Time | 1 S |
| Inherent Error | ≤ ± 15 % |
| Alarm Threshold | Continuous adjustable within the entire measuring range |
| Coefficient Of Variation | < 10 % |
| Stability | Drift is less than 10 % of the index value within 500 hours |
| Power Supply | AC 220 V |
| Host Machine Size | 16.14 in x 9.05 in x 5.23 in (410 mm x 230 mm x 133 mm) |
| Probe Size | Diameter: 2.75 in (70 mm) High: 11.22 in (285 mm) |
| Weight | Host machine: 13.22 lb. (6 kg) Probe: 1.32 lb. (0.6 kg) |
