Features
- Large backlit LCD equips multiparameter pH/conductivity meter
- Auto-buffer recognition, 1-5 points push-button calibration included
- Custom calibration solutions or selectable pH buffer groups (USA/NIST/DIN)
- pH slope, offset display; automatic electrode diagnosis integrated
- Automatically recognizes conductivity standard solutions, 1-5 points calibration
- Selectable cell constant, reference temperature, TDS factor modes
Technical Specifications
| pH Range | -2.000 pH to 20.000 pH |
| pH Accuracy | ±0.002 pH |
| pH Resolution | 0.1 pH, 0.01 pH, 0.001 pH, selectable |
| pH Calibration Points | 1 to 5 points |
| pH Buffer Options | USA, NIST, DIN or Custom |
| mV Range | ±1999.9 mV |
| mV Accuracy | ±0.2 mv |
| mV Resolution | 0.1 mV, 1 mV, selectable |
| Conductivity | |
| Range | 0.01 µs/cm to 20.00 µs/cm, 200.0 µs/cm, 2000 µs/cm, 20.00 ms/cm, 200.0 ms/cm |
| Accuracy | ±0.5% F.S |
| Resolution | 0.001, 0.01, 0.1, 1 |
| Points | 1 to 5 points |
| Calibration Solutions | 10 µs/cm, 84 µs/cm, 1413 µs/cm, 12.88 ms/cm, 111.8 ms/cm |
| Temperature Coefficient | 0.0 to 10.0%/°C |
| Compensation Modes | Linear or Pure water |
| Cell Constant | K=0.1, 1, 10 or Custom |
| Reference Temperature | 20 °C or 25 °C (68 °F or 77 °F) |
| TDS | |
| Range | 0 ppm to 10.00 ppm, 100.0 ppm, 1000 ppm, 10.00, 100.0 ppt (Max. 200 ppt) |
| Accuracy | ±1% F.S |
| Resolution | 0.01, 0.1, 1 |
| Factor | 0.1 to 1.0 (Default 0.5) |
| Temperature | |
| Range | 0 °C to 105 °C, (32 °F to 221 °F) |
| Accuracy | ±0.5°C (32.9 °F) |
| Resolution | 0.1 °F (0.1 °C) |
| Calibration Points | 1 point |
| General | |
| Calibration Range | Measured value ±50 °F (±10 °C) |
| Temperature Compensation | 32 °F to 212 °F (0 °C to 100 °C), Manual or Automatic |
| Data Hold | Manual or Auto-Endpoint |
| Stability Criteria | Low or High |
| Calibration Due Alarm | 1 to 31 days or off |
| Reset Function | Yes |
| Memory | Stores up to 500 data sets |
| Output | USB communication interface |
| Connector | BNC, 6-pin mini plug |
| Display | LCD |
| Power | DC 5 V, using AC adapters, 220 V AC /50 Hz |
| Temperature Compensation | 32 °F to 212 °F (0 °C to 100 °C), Manual or Automatic |
| Dimensions | 8.26 in × 7.40 in × 2.36 in (210 mm × 188 mm × 60 mm) |
| Weight | 2.20 lbs. (1.5 kg) |
