Features
- High resolution LCD display, 5.7 inches
- Multi-reading feature allows auto-read, timed-read and continuous-read
- Automatic or Manual temperature compensation ensures accurate results
- Auto-hold feature senses and locks the measurement endpoint
- Data Storage 500 sets (GLP-compliant)
- Support for USB or RS 232 communication
- The reset feature automatically resumes all settings back to factory default options.
- IP54 waterproof
- 1 5 points calibration with Standard Recognition
- Selectable pH buffer groups, including NIST, DIN, GB, USA
- Automatic electrode diagnosis with pH slope and offset display
- 1 to 5 points calibration
- Selectable measurement unit, including μg/L, mg/L, g/L, mmol/L, pX, ppm, ppb, etc
- Multi-measurement mode is supported, including Direct Reading mode
Technical Specifications
| pH Range | – 2.00 pH to 20.00 pH |
| pH Resolution | 0.1 pH, 0.01 pH |
| pH Accuracy | ± 0.01 pH |
| pH Calibration Points | Up to 5 |
| pH Standard Recognition | NIST, GB, DIN, USA buffers |
| mV Range | – 2000.0 to 2000.0 mV |
| mV Resolution | 0.1 mV, 0.01 mV |
| mV Accuracy | ± 0.1 mV or ± 0.03 % of reading whichever is greater |
| pX Range | -2.00 pX to 20.00 pX |
| pX Resolution | 0.1, 0.01 pX |
| pX Accuracy | ± 0.01 pX |
| pX Calibration Points | Up to 5 |
| ISE Range | 1.000e – 9 to 9.999e + 9 |
| ISE Resolution | Up to 4 significant digits |
| ISE Accuracy | ± 0.3 % |
| ISE Calibration Points | Up to 5 |
| Resolution | Temperature 0.1 |
| Reading Mode | Measurement Auto Read (Fast, Medium, Slow), Timed, Continuous |
| Reading Prompts | Measurement Reading, Stable, Locked |
| Temp. Compensation | Measurement ATC, MTC |
| Data Storage | Data management 500 results each |
| pH Electrode | Inputs BNC (Q9) |
| Temp. Probe | Inputs 4 pin aviation connector |
| USB | Outputs PC |
| RS 232 | Outputs printer |
| Auto Shutdown | Display options 1to 60 min, off |
| IP Rating | Display options IP54 |
| Date and Time | Display options Yes |
| Power | General AC Adapter, 100 V to 240 V AC input, DC 9 V output |
| Temperature Range | 23.0 ºF to 230 ºF (- 5.0 ºC to 110 ºC) |
| Dimensions | General (9.52 in x 7.67 in x 2.67 in) (242 mm × 195 mm × 68 mm) |
| Weight | 1.98 lb (0.9 kg) |
