Features
- Wireless network data transmission
- Real time monitoring 24 hours a day
- Flexible selection of system configuration
Technical Specifications
| Detection Method | Diffusion or Suction |
| Preheat Time | 90 Seconds |
| The Main Material | Cold Rolled Steel Plate |
| Installation Method | Outdoor Column Installation |
| Protection Class | IP53 |
| Meteorological Parameters | Temperature, Humidit, Wind speed & direction and Noise |
| Data Transmission | RS485 MODBUS or 4G LTE |
| Power Supply | AC 110 V to AC 230 V or solar energy |
| Measuring Range | 50 ppm |
| Resolution | 0.1 ppm |
| Indication Error | ≤ ± 10 % FS |
| Response Time | 120 Seconds |
| Measuring Range | 0 μg/m3 to 2000 μg/m3 |
| Sampling Cutter | Cyclone Physical Cutter |
| Sampling Time | Adjustable and Default Five Minutes |
| Resolution | 1 ug/m3 |
| Sampling Mode | Suction Type |
| Air Intake Heating | Heating And Dehumidifying According to Air Humidity |
| Malfunction Alarm | Real-Time Display of Fault Alarms |
| Zero Method | Automatic zero calibration |
| Humidity | 0 % RH to 95 % RH |
| Humidity Resolution | 1 % RH |
| Humidity Accuracy | ± 5 % RH |
| Wind Speed | 0 m/s to 60 m/s |
| Wind Speed Resolution | 0.1 m/s |
| Wind Speed Accuracy | ± 1 m/s |
| Wind Direction | 0 ° to 360 ° (A) to 130 dB (A) (A-weighted) |
| Wind Direction Resolution | 1 ° |
| Wind Direction Accuracy | ± 1 m/s |
| Atmospheric Pressure | 600 hPa to 1100 hPa |
| Atmospheric Pressure Resolution | 1 hPa |
| Atmospheric Pressure Accuracy | ± 1 m/s |
| Noise | 30 dB (A) to 130 dB (A) (A-weighted) |
| Noise Resolution | 1 hPa |
| Noise Accuracy | ± 3 dB |
| Rainfall | 0 mm/min to 4 mm/min |
| Rainfall Resolution | 0.1 mm |
| Rainfall Accuracy | ± 0.4 mm (≤ 10 mm) to ± 4 % (> 10 mm) |
| Illumination | 0 Lux to 200,000 Lux |
| Illumination Resolution | 0.1 mm |
| Illumination Accuracy | ± 7 % (25 ℃ or 77 ℉) |
| UV Radiation | 0 m W/㎡ to 400 m W/㎡ |
| UV Radiation Resolution | 1 m W/㎡ |
| UV Radiation Accuracy | ± 5 % |
| Temperature Resolution | 0.1 ℃ |
| Temperature Accuracy | ± 1 ℃ |
| Temperature | -22 ℉ to -58 ℉ (-30 ℃ to -50 ℃) |
| Size | 24.40 in x 17.32 in x 6.29 in (62 cm x 44 cm x 16 cm) |
