Features
- The F probes measure the thickness of non-magnetic materials on magnetic materials.
- Two measurement modes: Single and Continuous (Notice: Continuous mode is convenient to measure the coating thickness of curved objects and tiny objects.)
- Metric/imperial system selectable.
- Manual or automatic shutdown.
- Auto memory of calibration value, and auto recognize the substrate.
- The operation process has a buzzing reminder, while no buzzing in continuous mode.
- Use “USB data output” to connect with PC.
- Provide “Bluetooth™ data output” choice.
Technical Specifications
| Operating Principle | F Magnetic Induction |
| Measuring Range | 0.4724 in (0 mm to 12mm) |
| Resolution | 0.003937 in / 0.0003937 in (0.1 mm/0.01 mm) |
| Min. Radius Workpiece | F Type: convex 0.7874 in (20 mm) / concave 1.9685 in (50mm) |
| Min. Measuring Area | 0.6299 in (16 mm) |
| Min. Sample Thickness | 0.0118 in (0.3 mm) |
| Metric / Imperial | Convertible |
| Battery Indicator | Low Battery Indicator |
| Operating Conditions | Humidity: 10 to 90%RH |
| Power Supply | 4 x 1.5 V AAA (UM-4) Battery |
| Dimensions | 4.96 in x 2.55 in x 1.063 in (126 mm x 65 mm x 27 mm) |
| Weight | 0.46 lb. (0.21 kg) |
