Overview
Enviro Testers coating thickness gauge is a portable instrument for measuring coating which accurately measures the coating thickness. it can be used not only in the laboratory, but also in the project site. by using different test heads, it is the need of a variety of measurements. The instrument can be widely used in manufacturing, metal processing, chemical industry and commodity inspection is an indispensable instrument for material protection.
Technical Specifications
| Measuring Principle | Inductive |
| Measurement Purpose | Magnetic metal matrix |
| Measuring Range | 0 to 1500 um |
| Resolving Power | 0.1 / 1 um |
| Accuracy | ± (3% H + 1) um |
| Radius Of Curvature | Convex 0.5 in Convex (1.5 mm) |
| Work Environment | Temperature: 50°F to 104°F Temperature: (10℃ to 40℃) Relative humidity: 20 to 90% RH |
| Power Supply | 3 no.7 batteries |
| Size | 6.1 in x 2.6 in x 1.06 in (155 mm x 68 mm x 27 mm) |
| Weight | 0.5 lb (230 g) |
