Overview
Enviro Testers Coating Thickness Paint Gauge Meter wide measuring range for automotive and painting applications. It’s a top-quality rugged meter that uses magnetic induction & eddy current principle to measure thickness of magnetic and non-magnetic surface and detect the thickness of nonmagnetic coating on a magnetic substrate (ferrous, F) or an insulating coating on a non-magnetic conductive substrate (non-ferrous, NF).
Features
- Big LCD screen with backlight, display
- Automatic substrate recognition
- Built-in F & FN probe
- Single& Continuous measurement mode
- Automatic Calibration
Technical Specifications
| Type | Coating Thickness Meter |
| Screen Display | 4 digits, 0.39 in (10 mm) LCD |
| Probes | Built-in F probe & NF probe |
| Coating Thickness Range | 0 to 50 miles |
| Data Storage | Up to 99 groups of measurement |
| PC Interface | RS232C interface (CD and cable are not included in the set) |
| Power Supply | 2 x 1.5 V AAA battery |
| Single Package Size | 9.843 in x 7.7165 in x 2.0866 in (250 mm X 196 mm X 53 mm) |
| Single Gross Weight | 1.43 lb (0.650 kg) |
