Overview
Enviro Testers coating thickness tester gauge is a professional non-destructive testing instrument used to measure the thickness of nonmagnetic coatings and coatings on the surface of magnetic metal materials such as steel. Use the principle of magnetic induction measurement for fast non-destructive measurements. Magnetic thickness measurement method can be used to measure the thickness of non-magnetic coating on magnetic metal substrate (such as steel and iron) without damage (such as zinc plating, chromium, Gu, enamel, rubber, powder, paint, electrophoresis, enamel, plastic spraying, coating, anti-corrosion and fireproof coating, etc.). Application: Widely used in coating industry, manufacturing industry, metal processing industry, chemical industry, commodity inspection and other testing fields.
Applications
Widely used in coating industry, manufacturing industry, metal processing industry, chemical industry, commodity inspection and other testing fields.
Features
- Measuring speed, good sensitivity, high accuracy of measurement
- It has two test modes: SINGLE test (SINGLE) and continuous (CONTINUE) measurement model
- It is equipped with four statistical functions: the maximum (MAX), the minimum (MIN), average (MEA), frequency measurement
- Mass storage, can store 2000 measurements (10 groups, each group of 200 data)
- The function of storing, viewing and deleting data
- Three calibration methods: zero-point calibration, two-point calibration and multi-point calibration Upper and lower limit alarm function (Single measurement)
- The operation process is marked with beep (Single measurement)
- Automatic identification of iron-based and non-iron based materials
- Automatic recognition of Fe and NFe substrates
- Metric unit conversion μm/Mil
- Sunlight mode (used in strong light)
- 2.3 inches large color screen display, low voltage indicator
- Manual/automatic shutdown function
- Bluetooth with mobile phone APP real-time communication transmission data (only Bluetooth version)
Technical parameters
| Specification | Details |
| Measuring range | 0-6000μm |
| Minimum contact area | Φ16mm |
| Measurement accuracy | ± (3%) H＋2μm |
| Thinnest substrate | 0.4mm |
| Minimum Curvature | Convex 5mm; concave 25mm |
| Resolving power | 0.1μm /1μm |
| Power source | Three alkaline batteries |
| Display | 2.3-inch color screen |
| Using environment | 0℃-60℃ and 20%RH—90%RH, not strong magnetic place |
| Size | 130（L）×70（W）×25（H）mm |
| Weight | 100g |
