Features
- Adopt combined LED light source with high life and low power consumption, including UV / excluding UV
- Dual optical path system
- Large capacity storage space, which can store more than 30000 pieces of test data
- 2/10 standard observer’s angle
Technical Specifications
| Light Source | Combined full spectrum LED light source, UV light source |
| Sensor | Silicon photodiode array (double row 40 groups) |
| Wavelength | Range: 400 nm to 700 nm
Interval : 10 nm Semi band: 10 nm |
| Measurement System | Range : 0 % to 200 %
Aperature:MAV:Φ0,314961 in or Φ0,393701 in (Φ8 mm/Φ10 mm) SAV:Φ0,15748 in or Φ0,19685 in (Φ4 mm/Φ5 mm) Time : 1.5 s Mode: Single |
| Illuminance | D65 |
| Battery | 6000 measurement in 9 hour |
| Environment working | Operating: 32 F to 104 F (0 C to 40 C)
Storage: -68 F to 122 F (-20 C to 50 C) |
| Dimension | 5,07874 in x 2,99213 in x 0,669291 in (129 mm X76 mm X217 mm) |
| Weight | 1.32 lb (600 g) |
