Features
- Capable of outputting spectral data (1 nm and 5 nm pitches, unit: W･m-2･nm-1) in CSV format
- Measuring items and display modes suitable for industrial use
- All-in-one portable instrument can display, record, and graph measured values
- Abundant color rendering evaluation modes (CRI, TM-30-18, TLCI/TLMF, SSI)
Technical Specifications
| Power Supply | 5 V |
| Operating Temperature | -50 F to 104 F( -10 C to 50 C) |
| Illuminance | 1609 to 2006 for General Class A |
| Light System | Method: Incident Light
Receptor: White diffuser Element: CMOS Linear Image Sensor 128 pixel |
| Measurement System | Mode: Ambient light, CORD and Cordless |
| Accuracy | ±5% FS |
| Humidity | ±3% of indicated value |
| Display | 4.3 in |
| Dimension | 2,87402 in x 7,20472 in x 1,06299 in (73 mm x 183 mm x 27 mm) |
| Weight | 0.50 lb (230 g) |
