Features
- Leading humanity design and convenient operation
- Stable measurement performance
- Convenient and fast locating
- PC software realize more function expansion
- Advanced power management design
Technical Specifications
| Illuminating or view geometry | 8 per d |
| Measure aperture | 0.3 in (8 mm) |
| Detector | Silicon photoelectric diode |
| Locating | Illuminating locating or cross locating |
| Double measure end face | Large stable end face and small concave-convex end face |
| Color space | CIEL x a x b x C x h x CIEL x a x b x CIEXYZ |
| Color difference formula | E x ab L x a x b x E x C x h x |
| Light source | D65 or LED blue light excitation |
| Errors between each equipment | ≤0.50 e x ab |
| Storage | 100 pieces standards 20000 pieces samples |
| Repeatability | Standard deviation within e x ab 0.08, Average of 30 measurements of standard white plate |
| Lamp life | 3 years, more than 1 million measurements |
| Charging time | 8 hours 100% electricity |
| Power source | Rechargeable lithium-ion battery 3.7 V at 3200 mah |
| Size | 17.7 in x 9 in x 14.5 in (450 mm x 230 mm x 370 mm) |
| Weight | 5.5 lb (2.5 kg) |
