Technical Specifications
| Geometric Conditions | CIE recommended lighting reception method d or 8 |
| Colour Space | CIEL x a x b, CIEL x C x h, Yxy |
| Standard Light Source | A, C, D65, F2 (CWF) |
| Colour Difference Formula | CIE ΔE x ab, CIE ΔE x Ch |
| Light Source | Combination LED |
| Sensor Array | CCD at 2048 Pixels |
| Spectral Way | Diffraction grating |
| Measuring Caliber | 0.31 in (8 mm) |
| Observer | CIE 10-degree standard observer, CIE 2-degree standard observer |
| Wavelength Coverage | 400 nm to 700 nm |
| Wavelength Interval | 10 nm |
| Measuring Interval | 1.5 seconds |
| Measuring Range | 0 L to 100 L |
| Repeated Accuracy | ΔE < 0.08 (take the deviation average after 30 times measuring the white board) |
| Table Difference | ΔE < 0.5 (measure the X-Rite 24-color card) |
| Battery Power | Measuring 10000 times |
| Data Storage Capacity | Storage standard sample 100, Storage Sample 16000 |
| Light Source Life | Over 20000 hrs |
| Display Screen | TFT true colour 71.12 mm (2.8 in) @ 16:9 |
| Humidity Temperature | 14 °F to 104 °F (-10 °C to 40 °C) |
| Storage Temperature | -4 °F to 122 °F (-20 °C to 50 °C) |
| Working Humidity | Relative humidity less than 85% RH, without condensation |
| Size | 7.83 in x 2.67 in x 3.54 in (199 mm x 68 mm x 90 mm) |
| Weight | 4.40 lb (2 kg) |
