Overview
Enviro Testers combustible gas detector is an intelligent high-performance detection instrument that can continuously monitor a variety of gases (combustible gas and toxic and harmful gases). The instrument uses more than 20 kinds of plug-and-play smart sensors, including electrochemical toxic gas sensor, oxygen sensor and catalytic combustion sensor, the sensor can be configured flexibly in any combination (a combustible gas sensor is required in the four-in-one) to meet the analysis and detection needs of different industries.
Features
- Diffusion measurement method, short response time
- Intelligent temperature, humidity and zero-point compensation algorithm
- 3-inch full-color display
- Support PPM and mg/m3, % VOL and mg/L concentration units can be switched freely
- Standard configuration of 2000 mAh lithium battery
- First-class mechanical design
- Automatic layout according to the number of sensors
- The content displayed on the screen can be turned upside down (optional)
- Support measurement data download
Technical Specification
| Working principle | Electrochemical, infrared, TCD, PID, catalytic combustion (optional) |
| Detection range | 0 ppm to 1 ppm, 0 ppm to 10 ppm, 0 ppm to 50 ppm, 0 ppm to 100 ppm, 0 ppm to 200 ppm, 0 ppm to 500 ppm, 0 ppm to 1000 ppm, 0 ppm to 2000 ppm, 0 ppm to 5000 ppm, 0 ppm to 10000 ppm, 0 ppm to 50000 ppm, 0 % LEL to 100 % LEL, 0 % VOL to 5% VOL, 0 % VOL to 10 % VOL, 0 % VOL to 30 % VOL, 0 % VOL to 50 % VOL, 0 % VOL to 100 % VOL (optional) |
| Resolution | 0.01 ppm (0 ppm to 100 ppm); 0.1 ppm (0 ppm to 1000 ppm); 1 ppm (>1000 ppm); 0.1 % LEL; 0.01 % VOL |
| Sampling method | Diffusion type |
| Accuracy | ≤ ± 3 % F.S. |
| Repeatability | ≤ ± 1 % |
| Zero drift | ≤ ± 1 % (F.S. for year) |
| Response time | ≤ 30 s (T 90) |
| Recovery time | ≤ 30 s |
| Shell material | High-strength wear-resistant polycarbonate housing |
| Battery | Rechargeable lithium battery 2000 mAh, support mobile power supply and charging |
| Charger | USB quick charger 5 V 2.1 A |
| Alarm method | Sound alarm 95 dB at 30 cm, vibration alarm, red LED alarm light |
| Alarm value setting | A 1 alarm value, A 2 alarm value TWA, STEL alarm value can be set individually. |
| Screen | 2.3 in (58.4 mm) TFT |
| Button | 4 buttons navigation |
| Direct reading | Measured value, data recording status, maximum value, minimum value, average value |
| Data storage | Automatically store data, the storage interval can be customized, and can continuously store 300,000 groups of data with date and time |
| Data download | USB download |
| Calibration | Target point calibration function, can set the calibration value, zero adjustment with one key |
| Explosion proof | Exd ⅡC T4 Ga (Intrinsically Safe) |
| Protection class | IP 65 |
| Operation mode | User mode and administrator mode |
| Working humidity | 0 % RH to 95 % RH (Non-condensing) |
| Working temperature | – 4 °F to 122 °F (- 20 ℃ to 50 ℃) |
| Dimensions | 2.5 in x 4.7 in x 1.1 in (6.6 cm × 12 cm × 3 cm) |
| Weight | 7.05 oz (200 g) |
