Technical Specifications
| Measurement item | Refractive Index (nD), Brix, temperature |
| Measuring range | 1.32 RI to 1.39 RI or 0.0 Brix to 35.0 Brix |
| Resolution | 0.0001 RI or 0.1 Brix |
| Precision | ± 0.0003 RI or ± 0.20 Brix |
| Prism | Sapphire |
| Wetted parts | Stainless Steel SUS 316L |
| Power supply | 24 V DC |
| Interfaces | 1 output 4 mA to 20 mA,1 serial output RS485 |
| International Protection class | IP65 Water resistant |
| Process pressure | Max. 1 MPa (145 psi, 10 bar) |
| Cleaning components Options | IPRM Wiper |
| Fitting Options | IDF or ISO clamp union, Flange, Compression Fitting G1 or 4D |
| Special scale | More special scales are welcome to consult |
| Brix range | Temperature corrected 41 °F to 140 °F (5 ℃ to 60 ℃) |
| Process temperature | 32 °F to 140 °F (0 ℃ to 60 ℃) |
| Dimensions | 2.51 in x 3.54 in (64 mm x 90 mm) |
| weight | 1.14 lb (0.52 kg) |
