Overview
Enviro Testers Anti-corrosion Smart Display Handheld Ultrasonic Flowmeter is enable non-contact measurement of liquid flow. The sensor installed on the outer wall of the pipe completing the measurement of the flow. The characteristic of the product is the small size, the convenient carrying and the accurate measurement.
Feature
- Long test distance.
- High precision and stability. Interpreting the board thickness Intelligently can avoid man-made errors and reduce labor
- Fast and efficient . Test 3 to 5 point thickness within 3 minutes.
- Long service life of sensor. Improve the service life by paste abrasion resistance allowance on the bottom of sensor.
- The special clasp between extend bar and transmitting sensor can prevent its falling.
- Internal data storage. This function is convenient for laborer data management.
- Powerful data process and analysis software in Windows.
Technical Specifications
| Item | TEM H51 Board Thickness Tester |
| Type | Concrete Floor Slab Thickness Detector |
| Test scope | 1.575 in to 31.496 in (40 mm to 800 mm) |
| Permissible error | 0.787 inches to 7.874 in (20 to 200 mm ±1 mm) |
| Permissible error high range | 7.913 in to 177.165 in (201 mm to 4500 mm ±2 mm) |
| Data storage capacity | 32000 test points |
| Power supply | Integrated Batteries can work more than 30hrs |
| USB cable | Yes |
