Overview
Enviro Testers The instrument is a type of portable measuring gauge, capable of measuring rapidly, nondestructively, and precisely the thickness of coating and cladding material. It is suitable for onsite as well as for laboratory uses. Via the using of different probes, many sorts of measuring can be satisfied by the gauge. It can be applied comprehensively to manufacturing, metal processing and chemical profession as well as to commercial inspection. It is indispensable for the major of materials protection.
Feature
- Precise depth measurement
- Durable construction
- Easy-to-read display
- User-friendly interface
- Accurate and reliable readings
- Measuring range [specify the range, if available]
- Versatile applications
- Compact and portable design
- Quick and efficient measurements
- Calibration function
Technical Specifications
| Working principle | Magnetic induction and eddy current |
| Measurement accuracy | F1(±((1 to 2)%H+1)), F10(±((1 to 3)%H+1)), N1(±((1 to 2)%H+1)) |
| Measuring range | F1(0 to 1250 um), F10(0 to 10000 um), N1(0 to 1250 um) |
| Minimum curvature | F1 0.1181 in (3 mm),F10 0.3937 in (10 mm),N1 0.1575 in (4 mm),F400 0.0394 in (1 mm) |
| Minimum area | F1 (Φ7),F10 (Φ40),N1 (Φ5),F400 (Φ3) |
| Measurement method | Continuous measurement method, single measurement method |
| Statistics function | Mean, Large, Small, Tests, Standard Deviation |
| Calibration method | Single-point calibration, two-point calibration, and five-point basic calibration method to correct the system error of the probe |
| Storage function | Can store 495 measured values, with delete function: delete single suspicious data appearing in the measurement, or delete all data in the storage area for new measurement |
| Alarm system | Limits can be set: automatic alarming for measured values outside the limits; with power undervoltage indication function; beep prompts during operation; with error prompt function, error prompts can be displayed on screen or by beeps |
| Shutdown method | Manual shutdown mode and automatic shutdown mode |
| Use environment | 32 ºF to 104 ºF (0 to 40 ºC)/ humidity: 20%RH to 90%RH
Magnetic field-free environment |
| Power supply | Tow AA batteries |
| The standard configuration | Main unit 1 set/probe 1 set/ stan Dard piece(5 prices)/iron or aluminum base 1 piece/ 5 AA battery 2 sections/manual certificate warranty card 1 set |
