Features
- Using imported high-precision Infrared principles sensor
- LCD dot matrix display technology can display the type of gas, the gas unit, gas concentration values, measured maximum, local time, ambient temperature, etc.
- Support Chinese and English operation interface, easy to switch
- Gas concentration unit PPM, mg or m 3 can quickly switch display
- Built-in micro sampling pump, the pump suction size ten stalls adjustable
- Explosion-proof certification, proof grade: Exia II CT 4
Technical Specifications
| Gas Detected | Carbon dioxide gas co2 |
| Detection Principle | Infrared principles |
| Measure Range | 0 Vol to 10 Vol, 20% Vol |
| Resolution | 0.01% vol |
| Sampling Method | Pump- suction, flow up 1L/min, pump suction size ten stalls adjustable |
| Precision | 2% |
| Data Logger | 100,000 sets of data can be stored, storage space available set, minimum 5 S, can be browse |
| Response Time | ≤ 10 S |
| Repeatability | ≤ ± 1% |
| Zero Shift | ≤ ± 1% (F.S or Year) |
| Operating Language | Support in English |
| Explosion-Proof | Exia Ⅱ CT 4 |
| Alarm Mode | Sound, light, vibration |
| Recovery Time | ≤ 10 S |
| Linearity Error | ≤ ± 1% |
| Display | LCD dot matrix display technology |
| Gas Unit | Support for multiple gas unit switch display |
| Humidity | 0 RH % to 95% RH |
| Degree Of Protection | IP66 |
| Standard | 1 host computer, 1 charging plug, 1 aluminum alloy packing box, 1 manual,1 warranty card. |
| Optional | Data download (EXCEL format) function, detachable needle, hose, holster, waterproof and dust proof filter, high temperature probe (up to 1200 degrees) |
| Temperature | -40 ℉ to 158 ℉ (-40 ℃ to 70 ℃) |
| Dimensions | 8.07 in x 2.95 in x 1.26 in (205 mm x 75 mm x 32 mm) |
| Weight (Net Or Gross) | 0.72 lb (0.33 kg) |
