Features
- Ultraviolet light absorption
- Double light path structure
- Cramped construction
- It can be measured continuously online
- The test is more accurate after 10 minutes
Technical Specifications
| Detection principle | 254 nm UV absorption method, dual optical path principle |
| Measuring range | 0 mg/L to 200 mg/L |
| Resolution ratio | 0.1 mg/L |
| Accuracy/Repeatability | 0.5% |
| Zero shift | ≤±0.2% |
| Response time | ≤1S |
| Working pressure | <145.04 PSI(<1000.01Kpa) |
| Signal output | 4 mA to 20 mA, alarm (High or low concentration can be set) |
| size | 13.78 in x 14.96 in x 6.30 in (350 mm x 380 mm x 160 mm) |
