Features
- 5-inch touch screen: intuitive, rich display, simple operation
- Conforms to ASTM D0562, GB9269 coating testing standards
- Automatic measurement without weights; simplifies test procedures
- Real-time display data: KU value, load g value, cP value, °C value, test completion value lock display
- Machine automatically alarms if test range is exceeded
- Anti-static housing, metal lifting rod design; manual lifting frame structure; reduces test level control requirements
- Computer full-range linear correction ensures consistent accuracy
- Timing measurement function for practical fluid viscosity detection
- Test data output and print port included
- Optional accessories: PT100 temperature sensor, thermostatic bath, printer
Technical Specifications
| Test Range | 40 to 141.0 KU, 32 to 1099.0 g, 27 to 5274.0 cP |
| Rotation Rate | 200 RPM/min |
| Test Accuracy | ≤ ± 1 % (Newtonian fluid FS) |
| Reproducibility | ± 0.5 % |
| Control/Display Mode | 5 inch colour touch screen |
| Rotor | KU to 1 |
| Demand Amount of Test Sample | 0.33 oz (300 mL) |
| Display Information | KU, g, cP Values, Measurement Time, Temperature, Torque% |
| Test Data | Support the storage of 30 to group data |
| Viscosity Curve | Support real-time display and measurement of Visibility Curve |
| Stop Mode | Manual/automatic (timing measurement) |
| Power Supply | input AC 100 V to 230 V, output: DC DC12 V 2 A |
| Power | 40 W |
| Overall Dimensions | 11.81 in x 11.81 in x 17.72 in (300 mm × 300 mm × 450 mm) |
| Net Weight | 12.13 lbs (5.5 kg) |
