Features
• RG 1100 personal X Y radiation alarm dosimeter is a small high-sensitivity personal radiation dose alarm.
• The instrument uses GM counter tube as a detector sing strong single chip technology and has a strong anti-interference ability
• Mainly used to monitor the X ray and Y ray
• In the measurement range, can be arbitrarily set alarm threshold, when the alarm threshold is reached, an alarm to alert the staff in time to pay attention to safety
• Widely used in radiation processing enterprises, health and epidemic prevention
• Radiation therapy, nuclear laboratories, nuclear power plants, import and export
• Commodity inspection, building materials, petrochemicals, geological survey, scrap
• Steel, industrial non destructive flaw detection, ionization Radiation environment,
• Personal radiation dose monitoring and protection
• Using energy compensation GM tube, indicating the value of accurate,
• fast response,
• In a leading position
• High end OLED display, English interface, the dose rate LED strobe instructions,
• Simple and clear
• Dose rate, cumulative dose, blocking fault alarm function, sound, light, vibration
• Alarm any combination
• The alarm threshold is set arbitrarily within the range
• The alarm data is automatically stored for easy query
• Optional intelligent wireless networking, to achieve personal
• Intelligent wireless networking to achieve dose centralized management
Technical Specifications
| Detector | Energy Compensation Type GM counter tube |
| Power Consumption | Two AA batteries |
| Measuring Range | Dose equivalent rate: 0.01 µsv per h to 1 Ms v per h Cumulative dose equivalent: 0.00 MS V to 999.9 S v |
| Sensitivity | 1.5 CPS per USV per h (relative to 137 Cs) |
| Energy Response | 48 ke V to 3.0 Me V |
| Relative Error | < 5 % (at 1 mSv per h) |
| Temperature Characteristics | 50 °F to 122 °F (10 ℃ to 50 ℃) ≤ ± 10 % |
| Humidity Characteristics | 0 % RH to 95 % RH 95 °F (+35 ℃) ≤ ± 10 % RH |
| External Dimensions | 2.76 in x 1.58 in x 3.74 in (70 mm x 40 mm x 95 mm) |
| Weight | 0.220 lb (0.10 kg) |
