Technical Specifications
| Gas Detected | Combustible gas, toxic gas |
| Detection Range | 0 LEL % to 100 % LEL |
| Resolution Ratio | 1 % LEL |
| Measurement Error | Full Scale ±3 % LEL |
| Status Indication | LCD |
| Sampling Mode | Natural diffusion |
| Response Time | T90＜15 s |
| Power | DC 24 V ± 10 % |
| Output Signal | 4 mA to 20 mA or RS 485 |
| Explosion Proof Grade | Exd ⅡC T6 Gb |
| Ingress Protection | IP66 |
| Weight | ≤ 7.72 lb (3.5 kg) |
| Dimensions | 5.55 in x 7.01 in x 4.92 in (141 mm × 178 mm × 125 mm) |
