Features
- Sensors use imported sensitive elements, which have the characteristics of high accuracy, strong interchangeability and high reliability
- The internal machine core is in the form of components. Maintenance can be accomplished only by replacing components
- Independent liquid crystal display and acousto-optic alarm module, long life, can show the gas concentration working state on state on site and sound-light alarm
- Infrared remote-control technology, easy operation of zero calibration
Technical Specifications
| Detection Range | 0 PPM to 100 PPM |
| Accuracy | 1 PPM |
| Ex Level | Ex d Ⅱ C T6 Gb |
| Protection Level | IP66 |
| Output Signal | 4 mA 20 mA, RS485, switching value |
| Certifications | CE and SIL2 |
| Electrical Interface | G3 and G4 Thread |
| Display Type | LED Display |
| Size (L x W x H) | 8.07 in x 3.15 in x 8.46 in (20.5 cm x 8 cm x 21.5 cm) |
| Weight | 5.51 lb (2.5 kg) |
