Features
- Auto temperature compensation
- Precision filters to remove moisture and dust
- In-built memory for 2560 records
- USB port and Bluetooth 4.0 for data transfer
- Low battery and high alarm reminders
- IP65 dust and water resistance
Technical Specifications
| Flue gas CO (with H2-compensation) | |
| Measuring range | 0 ppm to 8000 ppm |
| Accuracy | ±10 ppm or ±10% of mv (0 ppm to 200 ppm) |
| ±20 ppm or ±5% of mv (201 ppm to 2000 ppm) | |
| ±10% of mv (2001 to 8000 ppm) | |
| Resolution | 1 ppm |
| Reaction time t 90 | <40 s |
| Flue gas CO low | |
| Measuring range | 0 ppm to 500 ppm |
| Accuracy | ±2 ppm (0 ppm to 39 ppm) |
| ±5% of mv (40 ppm to 500 ppm) | |
| Resolution | 1.0 ppm |
| Reaction time t 90 | <40 s |
| Flue gas Draught | |
| Measuring range | -9.99 hPa to +40 hPa |
| Accuracy | ±0.02 hPa or ±5 hPa (-0.50 hPa to +0.60 hPa) |
| 0.03 hPa to +1 hPa | |
| ±1.5% of mv (+3.01 hPa to +40.00 hPa) | |
| Resolution | 0.01 hPa with fine draught option 0.001 hPa |
| Temperature | |
| Measuring range | -40 °F to 2192 °F (-40 °C to 1200 °C) |
| Accuracy | ±33 °F (0.5 °C) (32 °F to 212 °F (0 °C to 100 °C)) |
| ±0.5 % of mv (Remaining Range) | |
| Resolution | 32.5 °F (0.1 °C) (-40 °F to 1830 °F (-40 °C to 999 °C)) |
| 33.8 °F (1 °C) (> 1832 °F (1000 °C)) | |
| Flue gas degree of effectivity, Eta (calculated) | |
| Measuring range | 0% to 120% |
| Resolution | 0.10% |
| Flue gas loss (calculated) | |
| Measuring range | 0% to 99.9 % |
| Resolution | 0.10% |
| Flue gas CO2 calculation (calculated from O2) | |
| Measuring range | 0 to CO2 max (Display range) |
| Accuracy | ±0.2 Vol.% |
| Resolution | 0.1 Vol.% |
| Pressure measurement | |
| Measuring range | 0 hPa to +300 hPa |
| Accuracy | ±0.5 hPa (0.0 hPa to 50.0 hPa) |
| ±1% of mv (50.1 hPa to 100.0 hPa) | |
| ±1.5% of mv (Remaining Range) | |
| Resolution | 0.1 hPa with fine draught option 0.01 hPa |
