Features
- The photosynthesis rate analyzer is compact and lightweight
- Easy to carry around, and can be measured anytime, anywhere
- The dot matrix LCD screen is 320 x 240
- English menu displays multiple information, the cursor guides the operation
- Open-circuit measurement and closed-circuit measurement are available
- The modification date, time, leaf area, volume, etc. can be set
- The measurement process and results are displayed and stored in time
- Historical data can also be viewed on the instrument
- Data stored in host can be imported into computer for secondary analysis
- Types of leaf chambers are suitable for different measurement objects
- It can be used both indoors and outdoors
- Both in vivo and in vitro can be measured
Technical Specifications
| CO Analysis | Non-Diffusion Infrared CO2 Analysis |
| Measuring Range | 0 ppm to 1000 ppm, 0 ppm to 1500 ppm, 0 ppm to 2000 ppm Resolution 0.1 ppm Accuracy 5 ppm |
| Leaf Chamber Temperature | High-precision digital temperature sensor |
| Blade Temperature | Platinum resistance |
| Leaf Humidity | High-precision digital humidity sensor imported from Switzerland |
| Measuring Range | 0% to 100%, resolution 0.1%, error ≤ ± 3% |
| Photosynthetically Active Radiation (PAR) | Silicon Photovoltaic Cells with Corrective Filters |
| Measuring Range | 0 μmolmm / s to 2500 μmolmm / s Accuracy: ≤ 5 μmolmm / s |
| Relative Humidity | 0% to 100% (no water vapor condensation) |
| Power Supply | DC 8.4 V lithium battery, can work continuously for 7 h to 9 h |
| Data Storage | 2 GB SD card |
| Working Environment | Temperature 32 °F to 122 °F (0 °C to 50 °C) |
| Measuring Range | 32 °F to 122 °F (0 °C to 50 °C) Resolution 32.18 F (0.1 °C) Error ± 32.36 °F (0.2 °C) |
| Three Leaf Chamber Sizes | Type I (0.79 in × 0.98 in (20 mm × 25 mm)) Type II (2.17 in × 0.79 in (55 mm × 20 mm)) Type III (2.56 in × 0.39 in (65 mm × 10 mm)) |
| The Standard Size | 2.17 in × 0.79 in (55 mm × 20 mm) |
| Size | 10.24 in × 10.24 in × 5.12 in (260 mm × 260 mm × 130 mm) |
| Weight | 7.2 lb (3.2 Kg) |
