Features
- 2 in (259.08 mm) (1024 Pixel x 600 Pixel) TFT LCD high brightness
- Clear picture, wide viewing angles
- Four wire resistive touch screen (4096 Pixel x 4096 Pixel)
- Powerful image display and data processing function
- Hidden embedded portable shape brings more convenience
- Support USB interface and large capacity
- Effective support long-term information collection
- Powerful PC analysis software
- Data acquisition, monitoring, recording, and controlling
Technical Specifications
| AC or DC Power | 85 V A to 265 V A or 24 V DC ±10% |
| Power Waste | ≤25 V A (The instrument input channel number affects actual power waste) |
| Channel Number | Jan-64 |
| Input Signals | Hot resistance Pt100, Cu50
Current4 mA to 20 mA, 0 mA to 10 mA, 0 mA to 20 mA Voltage 0 V to 5 V, 0 V to 10 V, 1 V to 5 V |
| Measurement Accuracy | ≤±0.2% FS |
| Recording Rates | 1 s to 19999 s |
| Recording Capacity (Reference68M) | 6 Days (64 channels inter-record gap1s) |
| 36 Days (64 channels inter-record gap1m) | |
| Recording Model | loop record |
| Alarm Type | free to set upper and lower limits for each channel alarm4 alarms each channel |
| Relay | TP1718 |
| Distribution | 24 V DC each channel |
| Communications | Standard RS 232C (or RS 484, USB, Ethernet, GPRS wireless communications, etc.) |
| Standard Modbus RTU communication protocol | |
| Materials | ABS |
| Operating Humidity | <85% RH |
| Storage Humidity | <95% RH |
| Operating Temperature | 32 ℉ to 122 ℉ (0 ℃ to 50 ℃) |
| Storage Temperature | -4 ℉ to 158 ℉ (-20 ℃ to 70 ℃) |
| Dimensions | 11.33 in x 1.10 in x 7.87 in (288 mm x 28 mm x 200 mm) |
| Panel Cutout | 10.94 in x 10.94 in (278 mm x 278 mm) |
| Weight | 8.38 lb (3.8 kg) |
