Features
- Using imported high-precision Infrared principles sensor
- LCD dot matrix display technology
- Can display the type of gas, the gas unit
- Display gas concentration values, measured maximum
- Display local time, ambient temperature, etc
- Support Chinese and English operation interface, easy to switch
- Gas concentration unit PPM, mg/m3 can quickly switch display
- Built-in adjustable micro sampling pump
- Explosion-proof
Technical Specifications
| Gas Detected | Nitrogen oxides NOX |
| Detection Principle | Electrochemical Principles |
| Measure Range | 0 PPM to 1.000 PPM, 0 PPM to 10.000 PPM |
| Resolution | 0.001 PPM |
| Sampling Method | Pump- suction, flow up 1 L/min, pump suction size ten stalls adjustable |
| Precision | 2% |
| Data Logger | 100,000 sets of data can be stored, storage space available set, minimum 5 S, can be browse |
| Response Time | ≤ 10S |
| Repeatability | ≤ ± 1% |
| Zero Shift | ≤ ± 1% (F.S / Year) |
| Explosion-Proof | Exia Ⅱ CT4 |
| Alarm Mode | Sound, light, vibration |
| Recovery Time | ≤ 10 S |
| Linearity Error | ≤ ± 1% |
| Degree of Protection | IP66 |
| Standard | 1 host computer, 1 charging plug, 1 aluminum alloy packing box, 1 manual,1 warranty card. |
| Optional | Data download (EXCEL format) function, detachable needle, hose, holster, Waterproof and dust-proof filter, High Temperature Probe (up to 1200 degrees) |
| Humidity | 0% RH to 95% RH |
| Temperature | -40 ℉ to 158 ℉ (-40 ℃ to 70 ℃) |
| Dimensions | 8.1 in x 3.0 in x 1.3 in (205 mm x 75 mm x 32 mm) |
| Weight(Net/Gross) | 0.72 Ib (0.33 Kg) |
