Technical Specifications
| Gas Detection | Single Gas, TWA, STEL |
| Gas Sensor Types | Electro-chemical, Catalytic Combustion, PID |
| Gas Range | As per request |
| Alert Value | As per request |
| Accuracy | ±3% F.S |
| Response Time | T 90 < 30 s |
| Humidity | < 95% RH, no condensation |
| Display | Large STN LCD indicating real-time or system state |
| Alarm | Audible, visual, vibration (≥85 dB, customizable) |
| Charging Time | 4 h to 6 h |
| Sampling Method | Natural diffusion |
| Power Supply | 3.7 V DC 1200 mAh rechargeable Li-ion battery |
| Fault Indication | Zero-point drift, sensor failure |
| Duration of Operation | < 300 h (non-stop) |
| Ingress Protection | IP 65 |
| Explosion Proof | Ex ia IIC T 4 Gb |
| Operating Temperature | −22 °F to 122 °F (-30 °C to 50 °C) |
| Dimensions | 4.01 in × 2.20 in × 1.02 in (102 mm x 56 mm x 26 mm) |
| Net Weight | 0.26 lb (0.12 kg including battery) |
