Features
- Remote monitoring
- Explosion-proof design
- Self-calibration
- Monitor ammonia gas
- Two-stage alarm
- Infrared controller
- Dual on-off signal output
Technical Specifications
| Gas Detected | NH3, Ammonia |
| Detection Principle | Electrochemical |
| Install Method | Wall-mounted, piping type, flow-type (according to the detected environment) |
| Measure Range | 0 to 100,200 ppm etc. |
| Resolution | 0.01 ppm etc. |
| Precision | ≤± 3% F.S. |
| Signal Output | 4 to 20 MA, RS485, relay |
| Response Time | ≤10 S |
| Recovery Time | ≤10 S |
| Repeatability | ≤± 1% |
| Linearity Error | ≤± 1% |
| Zero Shift | ≤± 1% (F.S/year) |
| Display | High light nixie tube display |
| Operating Language | G1/2 external thread explosion-proof flexible pipe |
| Gas Unit | ppm |
| Explosion-Proof | Ex d II CT6 |
| Degree Of Protection | IP65 |
| Alarm Mode | Sound, light |
| Operating Time | 24 h |
| Humidity | 0 to 90% RH |
| Temperature | -4 °F to 122 °F (-20 °C to 50 °C) |
| Dimensions | 7.08 in x 5.90 in x 3.54 in (180 mm x 150 mm x 90 mm) |
| Weight | ≤ 3.52 lb. (1.6 kg) |
