Features
- LCD Display
- 4 mA to 20 mA analog output support
- 220 V AC or 24 V DC power supply
- RS485 communication
- 304 stainless steel, Hastelloy, titanium materials
- Suitable for all kinds of single or mixed gases
- Various corrosive gases containing dust, sand, and moisture
- Ext IICT6 Gb explosion proof rating
- IP65 Protection level
Technical Specification
| Measurement Range | 0.5 Nm/s to 100 Nm/s (20 °C, 68 °F 14.69 PSI) |
| Accuracy | ±1% at not full scale ±0.5% at full scale |
| Range Ratio | Normally 100:1 (depending on the range of calibrated flow) |
| Pipe Diameter Range | 0.59 in to 236.22 in (15 mm to 6 m) |
| Ambient Temperature Range | no display: -40 °F to 185 °F (-40 °C to 85 °C)with display: -22 °F to 158 °F (-30 °C to 70 °C) Humidity: less than 90% RH |
| Medium Temperature Range | -40 °F to 212 °F (-40 ℃ to 100 °C), -40 °F to 392 °F (-40 °C to 200 °C), -40 °F to 842 °F (-40 °C to 450 °C), -40 °F to 950 °F (-40 °C to 510 °C) |
| Sensor Diameter | Φ3, Φ2.5 |
| Probe Diameter | Φ19 (standard), Φ16, Φ12 |
| Analog Output | 4 mA to 20 mA DC |
| Maximum Load | 10002 |
| Alarm | 1 or 2way relay output, 5 A 220 V, 5 A 30 V DC, key in setting |
| Large LCD Display | Seven-digit instantaneous flow rate, eight-digit cumulative flow rate |
| Process Pressure | 232.06 PSI (0.002 bar) max 2900.75 PSI (0.029 bar) |
