Overview
Enviro Testers Laser Remote Ammonia Gas Leak Detector is a high-tech advanced technology that detects ammonia leaking from long distances. It is a new generation of leak detection products, which greatly improves the efficiency and safety of walking inspection, the instrument available, widely recognized worldwide. It uses tunable laser spectroscopy (TDLS) to quickly detect gas leaks up to 20 meters away. People can effectively detect hard to reach or inaccessible areas within safe areas. Its use is not only effectively improving the efficiency and quality of walking inspection, but also makes easy which cannot reach or difficult to reach the place of inspection possible. It is lightweight, low energy consumption and can support long term continuous measurement tasks and can adapt to a variety of environmental needs (such as a wide range of operating temperature and pressure, high humidity, etc.). This product has a sensitive detection reaction ability, just 0.1 seconds to get the test results, detection accuracy up to 100 ppm m or even lower.
Features
- Intrinsically safe products
- Detection gas Ammonia
- Detection distance: 65.6 ft (20 m)
- Small size, light weight, easy to carry
- Low power consumption, can work for a long time
- Superior shockproof, waterproof and dustproof performance
- Fast response, large measuring range and high measuring accuracy
- It can realize data recording and Bluetooth transmission function
Technical Specifications
| Detection Method | harmonic laser spectrum theory |
| Detection Of Gas | NH3 |
| Sensor Type | infrared laser |
| Measuring Range | 0 ppm to 10000 ppm |
| Detection Distance | up to 65.6 ft (20 m) |
| Response Time | 0.1 s (1 s such as ranging) |
| Alarm | digital flashing alarm |
| Display Mode | LCD |
| Charging Mode | charging seat, 110 V AC to 240 V AC, 50 Hz or 60Hz |
| Power Supply | Rechargeable Lithium Battery (Replaceable Rechargeable Battery) |
| Working Hours | work 10 hours if fully charged |
| Relative Humidity | ≤ 99 % |
| Pressure | 80 kPa to 116 kPa |
| Material | ABS and PC |
| Self-Test Function | comes with self-test and calibration functions, without the need for daily calibration |
| Laser Protection Class | Class IIIR |
| Certification | Exia II CT6 |
| Protection Class | IP65 |
| Optional Accessory | ergonomic strap |
| Working Temperature | -4 °F to 122 °F (-20 °C to 50 °C) |
| External Dimension | 5.2 in x 2.8 in x 1.3 in (132 mm × 72 mm × 32 mm) |
| Machine Weight | 0.79 lb (0.36 kg) |
