Technical Specifications
| Accuracy | ±1% of reading at rates >0.2 mps |
| Repeatability | 0.2% |
| Principle | Transmit time |
| Velocity | ±32 m/s |
| Pipe Size | DN 15 mm to DN 6000 mm |
| Display | LCD with backlight, display accumulated flow or heat, instantaneous flow or heat, velocity, time etc. |
| Signal Output | 1 way 4 to 20mA output 1 way OCT pulse output 1 way relay output |
| Signal Input | 3-way 4 mA to 20 mA input achieve to heat measurement by connecting PT100 platinum resistor |
| Pipe Material | Carbon Steel, stainless steel, cast iron, cement pipe, copper, PVC, aluminum, FRP etc. Liner is allowed |
| Straight Pipe Section | Upstream: 10D; Downsteam:5D; From the pump:30D (D means outer diameter) |
| Liquid Types | All kinds of clean and pure liquids. |
| Liquid Turbidity | Less than 10000 ppm, with a little bubble |
| Flow Direction | Bi-directional measuring, net flow/heat measuring |
| Environment Humidity | Main Unit: 85% RH Transducer: standard is IP65, IP68(optional) |
| Cable | Twisted Pair Line, standard length of 5m, can be extended to 500m (not recommended); Contact the manufacturer for longer cable requirement. RS-485 interface, transmission distance up to 1000m |
| Power Supply | DC24 V |
| Power Consumption | Less than 1.5 W |
| Communication | MODBUS RTU RS485 |
