Features
- Measurement for TCs and RTDs
- Ambient temperature compensation
- Selectable slow ramp, fast ramp
- 24 V internal loop supply
- Power and read transmitter without carrying a DMM
- Charging and operating can be conducted simultaneously
- Ni-MH rechargeable batteries
Technical Specification
| DC Voltage | 0 V to 30 V |
| DC Current | 0 mA to 24 mA |
| Loop Power | 0 mA to 24 mA |
| DC Millivolt | -10 mV to 80 mV or -10 mV to 80 mV |
| Resistance | 0 Ω to 400 Ω or 400 Ω to 4000 Ω 5 Ω to 400 Ω or 400 Ω to 4000 Ω |
| Thermocouple | Type S, R, B, K, N, E, J, T |
| Resistance Temperature Detector (RTD) | Pt 100 (385), Pt 100 (3926), Pt 100 (3916), Pt 200 (385), Pt 500 (385), Pt 1000 (385), Cu 100 (ITS), Cu 50 (ITS) |
| Size (W x D x H) | 17.71 in x 11.81 in x 5.90 in (450 mm x 300mm x 150 mm) |
| Weight | 12.12 lb (5.5 kg) |
