Features
- High stability, precision in measurements
- PC software for data analysis and transmission
- Built-in thermal printer (56.5 mm paper width)
- Rechargeable Li-ion battery, 10 hours continuous use
Technical Specifications
| Measuring Principle | Magnetic induction (Fe) or Eddy current ( NFe) |
| Measuring Range (µm) | 0 μm to 1250 μm |
| Accuracy | ± [(1 to 2%) H+1] μm H refers to the thickness of testing piece |
| Minimum Resolution | 0.1 μm |
| Min Curvature Of The Min Area | Convex 1.5 Concave 9 |
| Diameter Of The Min Area | 7 |
| Critical Thickness Of Substrate | 0.5 |
| Operating Temperature | 32 °F to 104 °F (0 ºC to 40 ºC) |
| Magnetic Field | No strong magnetic field environment |
| Memory | 500 groups measured data |
| Dimensions | 9.05 in × 3.38 in × 1.81in (230 mm × 86 mm × 46 mm) |
| Weight | 0.88 lb (400 g) |
| Printer | Build-in High-speed Thermal Printer |
| Power Supply | Rechargeable Li-ion battery |
| Standard Configuration | Main unit,5 specimens (1.90 in, 3.92 in, 9.80 in, 20.19 in, 40.31 in (48.5 mm,99.8 mm,249 mm,513 mm, 1024 mm)), Charger, paper for printer, Fe or NFe probe & substrate |
| Optional Accessories | Probes, Specimens, Paper for printer |
