Technical Specifications
| Measuring Range | 9.84 ft, 16.40 ft, 32.80 ft, 65.61 ft, 98.42 ft (3 m, 5 m, 10 m, 20 m, 30 m) |
| Display Resolution | 0.03 in (1 mm) |
| Short Time Repetition Rate | 0.03 in (1 mm) |
| Measuring Error | 1% to 1% (Excessive wall thickness and instability of pressure and temperature may affect measurement precision.) |
| Span Shift | 32.80 ft (±10 m) |
| Current Output | 4 mA to 20 mA, Max Load 750 Ω |
| Communication Interface | RS 485, IrDA |
| Ambient Temperature For Operation Panel | -58 ℉ to 158 ℉ (-50 ℃ to 70 ℃) |
| Ambient Temperature For Ultrasonic Probe | -58 ℉ to 248 ℉ (-50 ℃ to 120 ℃) (Probe with a wider temperature range is available) |
| Ambient Humidity | 15% to 100% RH |
