Technical Specifications
| Type | Monocular |
| Magnification | 1x |
| Pupil diameter | 0.6 in (15 mm) |
| Pupil Distance | 0.99 in (25 mm) |
| Detector | 12 μm, 640 x 512 |
| Infrared FOV | 25.8° x 19.1° |
| Infrared focal length | 0.63 in (16 mm) |
| Dioptre Range | -3.5 to 2.5 |
| Battery Life (All Functions) | ≥8 hrs |
| Battery Life | ≥60 hrs |
| Display Mode | Black-hot/ White-hot/ Orange-hot, Outline, Target highlight |
| Compass indication | Azimuth/ Pitch angle/ Inclination angle |
| IIT FOV | 40° |
| Observational Distance for Human | Identify: 656.1 f (200 m), Identification: 1312.3 f (400 m), Detection: 4921.2 f (1500 m) |
| Observational Distance for Vehicle | Identify: 1640.4 f (500 m), Identification: 3280 f (1000 m), Detection: 9842 f (3000 m) |
| Weight | ≤0.84 lb (≤380 g) |
| Operating Temperature | -40 °F to 140 °F (-40 ℃ to 60 ℃) |
