Features
- RS-485 output, MODBUS/RTU support, digital sensor
- Built-in temp sensor, auto temp compensation
- 3/4″ NPT threads, easy upper/lower mounting
- Low power consumption, anti-interference circuit design
Technical Specifications
| Measured Range | 0 mg/L to 1000 mg/L(Customizable) |
| Principle | lon selective sensor |
| Temp Range | 32 ºF to 122 ºF (0 °C to 50 °C) |
| Output Signal | RS 485 or 4 mA to 20 mA |
| Pressure Range | 0 PSI to 14.50 PSI (0 MPa to 0.1 MPa) |
| Temperature Sensor | NTC10 K |
| Housing Materials | PP + PVC |
| Membrane Resistance | <500 MQ |
| Calibration | Standard liquid calibration |
| Accuracy | 2.50% |
| Resolution | 0.1 mg/L |
| Connection Method | 4 or 6 core cable |
| Threaded Connection | NPT3 / 4” |
| Cable Length | 1O m or Customize |
| Wire Connection | Pin, BNC or Customize |
