Features
- Explosion Proof
- Anti-Dust
- Easy Operation
- Multi-Monitor
- Circuit Protection
Technical Specifications
| Detecting Gas | CO2 |
| Sensor Type | NDIR |
| Measure Range | 0% VOL to 5% VOL |
| Resolution | 1 ppm |
| Power Supply | DC 12 V to 24 V |
| Alarm Type | Sound and Light Alarm |
| Accuracy | ± 3 % FS |
| Repeatability | 2 % |
| Response Time | Less than 20 Seconds |
| Supply Power | 10 VDC (Volts Direct Current) to 30 VDC |
| Consumption | Less than 2.5 W |
| Output Signal | 4 mA to 20 mA |
| Relay | 2 Relays |
| Audible And Visible Alarm | Optional |
| Main Material | Aluminium and Stainless Steel |
| Range | 0 ppm to 2000 ppm or 5000 ppm or 10000 ppm |
| Explosive Certificated | Exd II CT6 Gb |
| Fire Certificated | CCCF |
| Protection Grade | IP66 |
| Temperature | -40 °F to 158 °F (-40 ℃ to 70 ℃) |
| Dimensions | 8.5 in x 7.4 in (216 mm x 190 mm) |
| Weight | 3.5 lb (1.6 kg) |
