Technical Specifications
| Measuring Range | Oxygen content 0 mg to 20 mg/L Saturation 0% to 200% |
| Accuracy | ±1% FS |
| Resolution | Oxygen content 0.01mg/L Saturation 0.1% |
| Repeatability | ±0.5% FS |
| Resolution(Temperature) | 32.18 °F (0.1 ℃) |
| Correction Accuracy (Temperature) | ±0.5 ℃ |
| Temperature Measurement Type | Manual/Auto (NTC 10K / PT 1000) |
| Power Supply | AC 220 V ±10%, 50 Hz/60 Hz |
| Relay Alarm | 250 V AC/3 A |
| Communication | RS 485 (compatible with MODBUS RTU) |
| Transmitting Function | Isolated transmission 4 mA to 20 mA output, maximum loop 750 Ω, 0.1% FS |
| Temperature Range | 14 °F to 140 °F (−10 °C to 60 °C) |
| Meter Size | 3.77 in × 3.77 in × 5.11 in (96 mm x 96 mm x 130 mm) |
